CoroMill® Plura ball nose for ISO S profiling
Profiling excellence in ISO S
Your first choice for ISO S profiling
Providing an outstanding surface finish and unparalleled tool life, CoroMill® Plura ball nose is your first choice for profiling (semi-finishing to finishing) operations in titanium and HRSA.
A six-edged productivity boost
Featuring up to six flutes, CoroMill® Plura ball nose offers market-leading productivity levels while maintaining uncompromising surface quality.
Superior performance with Zertivo™ 2.0
CoroMill® Plura ball nose provides two grades with Zertivo™ 2.0 coating optimized for profiling of titanium alloys (T2CH) and HRSA (R2AH).
When to use
- Profiling (semi-finishing to finishing) of components such as blisks and blades
Product range
Standard assortment
Titanium (secondary application area: ISO M)
- Number of flutes: 4–6
- Diameter range: 3–20 mm, 0.125–0.750 inch
- APMX: 1.5×D
- LU: 3×D, 5×D
- Grade: T2CH
HRSA (secondary application area: ISO H)
- Number of flutes: 5–6
- Diameter range: 3–20 mm, 0.125–0.750 inch
- APMX: 1.5×D
- LU: 3×D, 5×D
- Grade: R2AH
Features
- Newly developed face geometry to avoid unfavorable cutting conditions in the center
- Uneven tooth pitch for the best dynamic stability, avoiding vibrations
- Highly optimized tool geometries with up to six flutes
- Dedicated grades for titanium alloys (T2CH) and HRSA (R2AH) with Zertivo™ 2.0 coating
- Specific edge preparation for the highest tool life and reliability
Benefits
Improved productivity:
- Enhanced cutting performance
- A higher number of flutes allows for higher feed rates ensuring the same surface quality
- Reduced machining time
- Lower cost per part
Extended tool life and process security:
- Enhanced durability and wear resistance
- Reduced risk of tool breakages or defects
- Stable production processes with fewer interruptions
Accuracy and repeatability:
- Consistent, high-quality results across multiple applications
Additional information
Also available in a Tailor Made version within the Customized solutions range.
For complex application needs, we also offer bespoke product design and manufacturing through advanced engineered solutions.
Join us in creating a sustainable future by recycling used carbide tools.
Experience the digital yellow coat experience with our CoroPlus® Tool Guide platform to support your application needs.
 | Profile milling | +++ |
| Shank | Cylindrical | |
| Face geometry |  | |
| Grade | T2CH | R2AH |
| ISO material |  |  |
Tool holding recommendations
Use CoroChuck™ 930 to maintain efficient production through quick and easy tool set-ups and changes.
Demo: Blisk profiling
Watch our end mill profiling tools in action.
Proven solutions
Our trusted aeroengine feature solutions, refined over many years, are just a click away.
